Adagio 2A3

Adagio is a crucial part of Auris integrated amplifier offer which comes in two variants: Adagio 300B and Adagio 2A3.

The 2A3 is an integrated amplifier with special DC heating of output tubes and precisely stabilized voltage heating of input tubes.

PCB architecture is strictly designed and defined.

The amplifier is designed in single-end technology, with controlled steady electricity which is evident in the amplifiers sonic.

Class operation
Configuration
Vacuum tubes
Load impedance
Frequency response
Output power
Input impedance
S/N
THD

Class A
Single End
2 x 2A3, 2 x 6SN7, 5U4G
4 Ω and 8 Ω
15 Hz -32 kHz
2 x 4W
47 kΩ
76 dB
0.6 % / 1 W, 4.4 % / 4 W

Power supply
Power consumption
Input
Output
Volume Control
Remote Control
Dimensions (WxDxH) mm
Weight (kg)
Cables

220 V (other on request)
160 V A
4 x line RCA
4 Ω and 8 Ω
Yes
Yes
450 x 400 x 270
20,5
Not included

Specifications are subject to change without prior notice.
